TECHNICAL SPECIFICATIONS
Excavator weight

20 ÷ 45 tons
Attachment operating weight*

2800 Kg
Max opening

1000 mm
Height

2440 mm
Width

1540 mm
Jaw width

520 mm
Oil delivery

150 ÷ 250 l/min
Maximum working pressure

350 bars
Maximum clamping force at tip

105 tons
Maximum clamping force at shears

355 tons
Shear length

240 mm
Max cutting diameter

50 mm
Min. closure time

2 s
Min. opening time

2 s
Hydraulic connections

1”
Mounting bracket compatibility

HP 5000
Type of carrier

– Wheeled excavator
– Tracked excavator
