Flail-Tec E2 Range
Flail-Tec is a dynamic and innovative company specialising in manufacturing heads for excavators, tractors, skid steers, and tracked vehicles tailored for the forestry and agricultural sectors. With our continuously growing product line and unwavering dedication to quality, productivity, and durability, our goal is to deliver world-class industry solutions to our customers.
Flail-Tec E2-100
At Flail-Tec, our mission is to empower forestry and agricultural professionals with cutting-edge mulching technology that enhances productivity, minimizes environmental impact, and promotes sustainable land management practices.
E2 Range Key
Flail-Tec E2-120
At Flail-Tec, our mission is to empower forestry and agricultural professionals with cutting-edge mulching technology that enhances productivity, minimizes environmental impact, and promotes sustainable land management practices.
E2 Range Key
Flail-Tec E2-140
At Flail-Tec, our mission is to empower forestry and agricultural professionals with cutting-edge mulching technology that enhances productivity, minimizes environmental impact, and promotes sustainable land management practices.
E2 Range Key
Flail-Tec E2-80
At Flail-Tec, our mission is to empower forestry and agricultural professionals with cutting-edge mulching technology that enhances productivity, minimizes environmental impact, and promotes sustainable land management practices.
E2 Range Key
Robust double skinned design
Manifold block with anti-cavitation protection valve,
pressure relief and flow control included as standard.
Customised hitch bracket
Motor enclosure with easy access hatch
Conveniently positioned grease nipple locations
Robust SKF bearing used on support roller
Heavy duty skids with 2 height settings
Short Facts Download
Find all the information on this product at a glance in this pdf
FLAIL-TEc E2 RANGE features:
- 11cc to 36cc geared motor suitable for auxiliary flows of 25l/min to 90/min and up to 250 bar pressure
- Manifold block with anti-cavitation protection valve, pressure relief valve and flow control included as standard
- Belt drive transmission system
- Motor enclosure with easy access hatch
- Projectile protection chains
- Sealed body and rotor ends protects form dirt and dust buildup
- Heavy duty SKF bearings
- Conveniently positioned grease nipple locations
- Heavy Duty Sliding Skids with 2 height options
- Robust double skinned design
- 5” support roller with heavy duty SKF bearings
| E2-80 | E2-100 | E2-120 | E2-140 | |
|---|---|---|---|---|
| Excavator weight (t) | 3-6 | 3.5-6 | 6-13 | 6-13 |
| Flow rate (L/min) | 25-90 | 25-90 | 40-90 | 40-90 |
| Pressure (bar) | 180-250 | 180-250 | 180-250 | 180-250 |
| Working Width (mm) | 807 | 1007 | 1207 | 1407 |
| Weight (kg)* | 261 | 299 | 398 | 414 |
| Rotor Cutting Diameter (mm) | 395 | 395 | 395 | 395 |
| Number of Hammer Flails | 8 | 10 | 12 | 14 |
| Number of Y & Straight Blades | 8x3 | 10x3 | 12x3 | 14x3 |
