Ferris SRS Z1

The Soft Ride Stand-on SRS™ Z1 is raising the bar with our patent pending adjustable operator platform, featuring suspension technology, optimising operator comfort and increasing  productivity! The superior balance provides stability and manoeuverability that exceeds expectations for traction and handling.

The Soft Ride Stand-on SRS™ Z1 is designed to allow for quick operator exit and re-entry. Need to walk away from the mower to move an obstacle or debris? The PTO will automatically disengage when the operator leaves the platform. Restarting the blades is just as easy. When the operator steps back onto the platform and re engages the PTO switch they can continue mowing.

  • Productive – up to 1.25 hectares/hour (based on 80% efficiency)
  • Speed – 12.8km/h ground speed for faster mowing
  • Comfortable – patent pending suspension platform and ergonomic thigh pad for high operator comfort
  • Height of cut – easy to change from the operator compartment, for no-hassle curb mounting and trailer loading
  • Keep going for longer – generous 23 litre fuel tank with side-located filler neck for easy refuelling
  • Speed control – easy locking 3-position speed control requiring no tools and conveniently located

Specification

SRSZ1KAV1936RDCE

Engine
Make Kawasaki – Petrol
Model FX600V
Horsepower 19,0 HP
Cylinders / Displacement 2 Cylinders V-Twin / 603 cc
Cooling Air-cooled
PTO Electric PTO clutch
Starting Electric
Fuel Capacity 23 Litres
Mower
Cutting width (cm/inch) 91 cm / 36” Rear Discharge
Deck Configuration Rear discharge/mulching insert and mulching blades
Cutting Height (cm) 44 – 114 mm
Deck Construction 3,4 mm fabricated construction, double top deck, double reinforced side skirts, overlap welded corners, round trim edge
Mower Spindles Cast aluminium 133 mm; 25,4 mm shaft
Deck lift system Hand-operated, spring assisted
Suspension & Drive Train
Suspension Patent pending adjustable suspension platform
Transmission Independent Hydro-Gear® ZT-3400™ transaxles
Drive Axles 28,6 mm Tapered with 4-bolt flange
Drive Tyres (inch) 23 x 8.50 – 12 (4 ply)
Caster Tyres (inch) 11 x 4.00 – 5 (4 ply) Flat free
Noise and Vibration
HAV < 2.5
WBV <0.5
Sound dB(A) 100
Ground Speed
Speed-fwd. (km/h) 0 – 12,8 km/h
Speed-rev. (km/h) 0 – 6,4 km/h
Dimensions
Overall length (cm) 162
Overall width (cm) 92
Dry weight (Kgs) 368
Operator Control & Comfort Systems
Roll-Over Protection Structure N.A.
Instrumentation Hour meter, fuel level gauge
Controls Integrated forward & reverse control levers with stability bar, Automatic PTO Restart
Parking Brake / Safety Circuit Internal transaxle brake / Operator presence in platform, Parking brake safety circuit for starting engine
Warranty
Engine 3-Year Manufacturer’s Limited Warranty
Transmission 2-Year Manufacturer’s Limited Warranty
Balance of machine 4-Year Limited Warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 4 years (48 months) unlimited hours. Belts, Tires, Brake Pads, Battery, Blades: 90 days

Specification

SRSZ1KAV2248RDCE

 Engine
Make Kawasaki – Petrol
Model FX691V
Horsepower 22,0 HP
Cylinders / Displacement 2 Cylinders V-Twin / 726 cc
Cooling Air-cooled
PTO Electric PTO clutch
Starting Electric
Fuel Capacity 23 Litres
Mower
Cutting width (cm/inch) 122 cm / 48” Rear Discharge iCD™
Deck Configuration Rear discharge/mulching insert and mulching blades
Cutting Height (cm) 44 – 114 mm
Deck Construction 3,4 mm fabricated construction, double top deck, double reinforced side skirts, overlap welded corners, iCD technology
Mower Spindles Cast aluminium 133 mm; 25,4 mm shaft
Deck lift system Hand-operated, spring assisted
Suspension & Drive Train
Suspension Patent pending adjustable suspension platform
Transmission Independent Hydro-Gear® ZT-3400™ transaxles
Drive Axles 28,6 mm Tapered with 4-bolt flange
Drive Tyres (inch) 23 x 10.50 – 12 (4 ply)
Caster Tyres (inch) 11 x 4.00 – 5 (4 ply) Flat free
Noise and Vibration
HAV < 2.5
WBV <0.5
Sound dB(A) 105
Ground Speed
Speed-fwd. (km/h) 0 – 12,8 km/h
Speed-rev. (km/h) 0 – 6,4 km/h
Dimensions
Overall length (cm) 166
Overall width (cm) 124
Dry weight (Kgs) 398
Operator Control & Comfort Systems
Roll-Over Protection Structure N.A.
Instrumentation Hour meter, fuel level gauge
Controls Integrated forward & reverse control levers with stability bar, Automatic PTO Restart
Parking Brake / Safety Circuit Internal transaxle brake / Operator presence in platform, Parking brake safety circuit for starting engine
Warranty
Engine 3-Year Manufacturer’s Limited Warranty
Transmission 2-Year Manufacturer’s Limited Warranty
Balance of machine 4-Year Limited Warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 4 years (48 months) unlimited hours. Belts, Tires, Brake Pads, Battery, Blades: 90 days
