TECHNICAL SPECIFICATIONS

Excavator weight

6,5 ÷ 16 tons
Equipment weight*

630 Kg
Height

93 cm
Baseplate size

46 x 84 cm
Centrifugal force

4000 Kg – 39 KN
Compacting force (Min – Med – Max)

0,9 – 1,1 – 1,4 Kg/cm²
8,8 – 10,8 -13,7 N/cm²
Frequency (Min – Med – Max)

1600 -1850 – 2100 rpm
27 – 31 – 35 hz
Oil flow to motor

55 ÷ 75 l/min
Maximum working pressure adjusted to the excavator

200 bars
Maximum backpressure

21 bars
Oil delivery for rotation

10 l/min
Pressure regulated for rotation

90 bars
Compatibility of attachment plate with mounting bracket

HP 900
Type of carrier

– Compact excavator
– Backhoe loader
– Wheeled excavator
