Features:

• Developed for felling trees with large stems..
• Allows felling, sectioning and handling logs, with the same
  machine.
• 2 “two-way flow” hydraulic circuits.
• One 6-way solenoid valve ¾” to switch the grapple into the saw
  bar line.
• 7 claws with 30 mm thickness and maximum grab opening of
  2200 mm.
• Grab piston of 33 tons clamping force with block and pressure
  relief valve on cylinder.
• Inlet pressure relief valve on saw bar.
• Watertight rotation case.
• Gear transmission with Ø 700mm slewing ring.
• Clamp and frame constructed entirely in Hardox 400 steel.
• Drainage on precharged accumulator.
• Four 800cc orbital motors.
