The OMEF cone splitter and spiral splitter effortlessly break down large pieces of timber and tree stumps to create manageable, useful pieces of timber for firewood processing, wood chipping or shredding, and biomass fuel creation. Cone splitters are used across a range of industries including biomass harvesting, forestry, land clearing, stump reduction and landscaping. These hydraulically powered cone splitters can be attached to excavators, forklifts and tractors.
Enquire about hiring this product
2.6 ARB digger
Attachment Options Available:
- Flail – Femac T3-90
- Grab – Intermercato TG16
- Tree Shear – OMEF 100
The SANY SY26U offers highly maneuverable and powerful performance to assist with timber handling, flailing, and tree dismantling operations. With a short tail swing design, the machine is especially suited to working in more confined areas.
OPERATOR COMFORT
With the SY26CU operators can look forward to maximum comfort and easier, fatigue-free operation.
+ Responsive and precise controls
+ Ergonomic and comfortable air suspension operator’s seat
+ Clear instrumentation and large high resolution colour display
+ Quiet, low vibration engine so noise levels are kept to a minimum
+ LED work lights for maximum visibility in low light conditions
| DIMENSIONS | |
| Overall length | 4,285 mm |
| Overall width | 1,550 mm |
| Overall superstructure width | 1,375 mm |
| Overall height above cab | 2,430 mm |
| Overall height of boom | 1,620 mm |
| Rear length | 775 mm |
| Track width | 1,250 mm |
| Undercarriage length | 2,005 mm |
| Undercarriage width (dozer blade) | 1,550 mm |
| Horizontal distance (dozer blade) | 2,940 mm |
| Blade height | 300 mm |
| Track height | 445 mm |
| Track link width | 300 mm |
| Minimal ground clearance | 290 mm |
| Clearance under counterweight | 555 mm |
| Height of engine hood | 1,460 mm |
| Tail swing radius | 775 mm |
| Distance (centre) between crawler wheel and guide wheel | 1,560 mm |
| Boom length | 2,100 mm |
| Bucket arm length | 1,300 mm |
| Bucket capacity | 0.06 m³ |
| WORKING RANGE | |
| Max. horizontal reach on the ground | 4,740 mm |
| Max. excavation depth | 2,820 mm |
| Max. vertical reach | 4,410 mm |
| Max. dumping height | 3,100 mm |
| Min. dumping height | 940 mm |
| Min. slewing radius | 2,110 mm |
| Max. excavation depth, vertical wall | 2,585 mm |
| Working machine height at min. slewing radius | 3,200 mm |
| Arm head distance with work equipment retracted as far as possible | 1,530 mm |
| Swing radius by min. boom swing Swing radius by max. boom swing | 1,795 mm L 1,815 mm R |
| Max. clearance when blade up | 360 mm |
| Max. depth of blade down | 330 mm |
| Max. boom swing angle | 540 mm L 765 mm R |
| Max. boom swing angle (deg.) | 67° L 51° R |
| ENGINE | |
| Model | 3TNV80F |
| Rated power | 14.6 kW |
| Max. torque | 64.7 Nm/1,800 rpm |
| Displacement | 1,267 l |
| Batteries | 1 × 12 V/55 Ah |
| HYDRAULIC SYSTEM | |
| Main pumps | 1 Adjustable axial piston pump |
| Maximum oil flow | 1 x 72 l/min |
| Travel drive | 2 Adjustable axial piston pumps |
| Slewing gear | 1 Adjustable axial motor |
| RELIEF VALVE SETTINGS | |
| Boom circuit | 245 Bar |
| Slewing circuit | 196 Bar |
| Drive circuit | 245 Bar |
| Pilot control circuit | 35 Bar |
| PERFORMANCE | |
| Slewing speed | 10 rpm |
| Slewing torque | 0.973 kNm |
| Max. ground speeds | fast 4.5 km/h slow 2.4 km/h |
| Max. traction force | 20 kN |
| Climbing ability | 0.25 |
| ISO bucket breakaway force | 27.4 kN |
| SAE: PCSA bucket breakaway force | 24.2 kN |
| ISO arm tear-out force | 14.39 kN |
| SAE: PCSA arm tear-out force | 13.83 kN |
| SERVICE REFILL CAPACITIES | |
| Fuel tank | 34 l |
| Engine coolant | 4.1 l |
| Engine oil | 3.4 l |
| Travel drive (per side) | 0.6 l |
| Hydraulic system | 45 l |
