This is a high capacity, Hi-tip bucket that transports high volumes of light material, such as sawdust, woodchip, bark, and greenwaste. It allows for tipping without the need of a loading ramp, increasing productivity and decreasing downtime. Its capacity ranges from 4.0m³ – 11m³
Dimensions | HD40 | HD50 | HD60 | HD70 | HD80 | HD95 | HD110 | |
Capacity (SAE Heaped) | 4.0m3 | 5.0m3 | 6.0m3 | 7.0m3 | 8.0m3 | 9.5m3 | 11.0m3 | |
Weight (Standard) | 2147kg | 2420kg | 2685kg | 2888kg | 2990kg | 3126kg | 3459kg | |
Overall Length | A | 1944mm | 2050mm | 2180mm | 2280mm | 2350mm | 2420mm | 2420mm |
Bucket Length | B | 1565mm | 1670mm | 1775mm | 1860mm | 1910mm | 1990mm | 1990mm |
Height | C | 1620mm | 1715mm | 1825mm | 2100mm | 2050mm | 2300mm | 2300mm |
Centre Of Gravity (Heaped) Width | D | 395mm | 420mm | 440mm | 490mm | 505mm | 523mm | 527mm |
D1 | 833mm | 880mm | 949mm | 979mm | 995mm | 1022mm | 996mm | |
Width (Standard) | 2700mm | 2750mm | 2800mm | 3000mm | 3000mm | 3000mm | 3400mm | |
Maximum load per m³ is 1000kg |
