TECHNICAL SPECIFICATIONS

Excavator weight

18 ÷ 36 tons
Attachment operating weight*

2300 Kg
Max opening

900 mm
Height

2510 mm
Width

1450 mm
Jaw width

450 mm
Oil delivery

140 ÷ 220 l/min
Maximum working pressure

350 bars
Maximum clamping force at tip

80 tons
Maximum clamping force at shears

265 tons
Shear length

240 mm
Max cutting diameter

45 mm
Min. closure time

3 s**
Min. opening time

1,5 s
Hydraulic connections

3/4”
Maximum rotation flow

25 l/min
Maximum rotation pressure

110 bars
Hydraulic connections for rotation

1/2”
Mounting bracket compatibility

HP 3000 ÷ HP 4000
Type of carrier

– Wheeled excavator
– Tracked excavator
